Thông tin chi tiết sản phẩm:
Thanh toán:
|
| Loại: | Van điều khiển đến van điện từ | Mã sản phẩm: | VOE14576859 14576859 |
|---|---|---|---|
| Tên sản phẩm: | Van | Số máy: | EC200B EC210B EC240B |
| Ứng dụng: | Máy xúc | thời gian dẫn: | 1-3 ngày để giao hàng |
| đóng gói: | Thùng xuất khẩu tiêu chuẩn | ||
| Làm nổi bật: | Excavator valve spare parts,EC200B valve fitting,EC210B excavator parts |
||
VOE14576859 14576859 Valve Excavator Spare Parts Fitting For EC200B EC210B EC240B
Specifiion
| Category | Servo System, Control Valve to Solenoid Valve |
| Name | Valve |
| Parts No | VOE14576859 14576859 |
| Machine Number | EC200B EC210B EC240B |
| Lead time | 1-3 DAYS |
| Quality | Brand new, OEM quality |
| MOQ | 1 PCS |
| Means of transport | By sea/air, DHL FEDEX UPS TNT |
| Packing | As request or standard packing |
| Working Principle | 1. Hydraulic oil at system pressure enters the valve’s inlet port and is blocked by the spool in the neutral position |
| 2. Actuation (manual lever, solenoid, or pilot pressure) moves the spool to open flow paths to outlet ports connected to actuators (cylinders/motors) | |
| 3. The spool’s position controls the volume and direction of oil flow: partial spool movement = reduced flow (slow actuator speed); full movement = maximum flow (full speed) | |
| 4. When actuation stops, the spring-centered spool returns to neutral, closing flow paths and holding the actuator in position | |
| 5. The integrated relief valve opens if pressure exceeds the rated limit, diverting oil back to the tank to prevent component damage | |
| Core Functions | 1. Flow & Pressure Regulation: Controls the volume and pressure of hydraulic oil to actuators, enabling precise speed and force adjustment (e.g., slow/fast boom movement, light/heavy lifting) |
| 2. Direction Control: Redirects oil flow to move actuators forward/backward (e.g., extend/retract excavator arm, lift/lower loader bucket) | |
| 3. Overpressure Protection: Built-in relief valve prevents hydraulic system damage from pressure spikes (e.g., sudden load impacts) | |
| 4. Position Holding: Spring-centered spool locks actuators in place when not in use, preventing unintended movement (critical for operator safety) | |
| 5. System Efficiency: Minimal internal leakage reduces energy loss, lowering fuel consumption and heat generation |
EXCAVATOR EC200B EC210B EC240B Vo.lvo.
| VOE14524582 Valve |
| EC120D, EC140B, EC140C, EC140D, EC140E, EC160C, EC180C, EC200B, EC200D, EC210B, EC210C, EC210D, EC220D, EC235C, EC235D, EC240B, EC290B, EC290C, EC750D, EC750E, ECR145C, ECR145D, ECR145E, ECR235C, ECR3... |
| VOE14522410 Valve |
| EC120D, EC135B, EC140B, EC140C, EC140D, EC140E, EC160B, EC160C, EC160D, EC160E, EC170D, EC180B, EC180C, EC180D, EC180E, EC210B, EC210C, EC210D, EC220D, EC220E, EC235C, EC235D, EC240B, EC240C, EC250D, ... |
| VOE14578201 Valve |
| EC200B, EC210B, EC240B |
| VOE14533067 Valve |
| EC210B, EW145B |
| VOE14578619 Valve |
| EC200B, EC210B, EC240B, EC290B |
| VOE14589627 Valve |
| EC210B, EC240B |
| VOE14525791 Valve |
| EC210B, EC240B, EC290B |
| VOE14574269 Valve |
| EC200B, EC210B, EC240B, EC290B, EC340D, EC360C, EC360CHR, EC380D, EC380DHR, EC460C, EC460CHR, EC480D, EC480DHR, EW145B, PL4809D |
| VOE14602562 Valve |
| EC240B, EC240C, FC2924C |
| VOE14633065 Valve |
| EC210B, EC240B, EC290B, EC330B, EC330C, EC340D, EC360B, EC360C, EC360CHR, EC380D, EC380DHR, EC460B, EC460C, EC460CHR, EC480D, EC480DHR, EC700B, EC700BHR, EC700C, EC700CHR, FC2121C, FC2421C, FC2924C, F... |
| VOE14684415 Valve |
| EC135B, EC140B, EC140C, EC140D, EC140E, EC240B, EC240C, EC250D, EC290B, EC290C, EC360B, EC700B, EC700C, ECR145C, ECR145D, ECR145E, EW145B, FC2924C, FC3329C, PL3005D |
| VOE14703868 Valve |
| EC140B, EC210B, EC290B |
| VOE14517071 Valve |
| EC135B, EC140B |
| VOE14522410 Valve |
| EC120D, EC135B, EC140B, EC140C, EC140D, EC140E, EC160B, EC160C, EC160D, EC160E, EC170D, EC180B, EC180C, EC180D, EC180E, EC210B, EC210C, EC210D, EC220D, EC220E, EC235C, EC235D, EC240B, EC240C, EC250D, ... |
| SA7270-11050 Valve |
| Volvo.Heavy |
| VOE16691837 Valve control |
| G900C |
| CH89104 Valve |
| G700 MODELS, G700B MODELS |
| VOE12762858 Valve |
| OMNI 318 |
| VOE14523619 Valve |
| ECR58, ECR88 |
| VOE12765895 Valve |
| P7170, P7170B |
| VOE14609872 Valve |
| EC140B |
| Pos. | Part No | Qty | Parts name | Comments |
| 1 | VOE14589627 | [1] | Valve | S/N -85051 |
| 2 | VOE14578191 | [2] | Plate | |
| 3 | VOE14579675 | [1] | Plate | |
| 4 | VOE14531096 | [1] | Block | |
| 5 | VOE14577530 | [1] | Block | |
| 6 | VOE14529064 | [1] | Grommet | |
| 7 | VOE14529326 | [1] | Grommet | |
| 8 | VOE14576859 | [1] | Valve | |
| VOE14550884 | [3] | Solenoid coil | ||
| 9 | SA1048-10530 | [1] | Connector | |
| 10 | SA1048-10540 | [2] | Connector | |
| 11 | SA9411-92321 | [1] | Connector | |
| 12 | SA9411-95190 | [1] | Elbow | |
| 13 | VOE14523778 | [2] | Filter | S/N -85051 |
| 14 | VOE14880126 | [1] | T-nipple | |
| 15 | SA9411-92350 | [1] | T-nipple | S/N -85051 |
| 16 | SA9411-95440 | [3] | T-nipple | S/N -85051 |
| SA9411-95440 | [2] | T-nipple | S/N 85052- | |
| 17 | SA9412-11020 | [6] | Nipple | S/N -85051 |
| SA9412-11020 | [7] | Nipple | S/N 85052- | |
| 18 | VOE14883808 | [1] | Nipple | |
| 19 | SA9412-11090 | [1] | Nipple | |
| 20 | SA9412-11120 | [1] | Connector | |
| 21 | SA9412-11130 | [1] | Nipple | S/N -85501 |
| 21 | VOE14884837 | [1] | Nipple | S/N 85502- |
| 22 | SA9412-31030 | [2] | Connector | S/N -85051 |
| 23 | SA9412-31040 | [1] | Connector | |
| 24 | SA9412-31060 | [1] | Connector | |
| 25 | SA9413-11010 | [3] | Elbow nipple | |
| 26 | SA9413-31020 | [1] | Elbow nipple | |
| 27 | SA9415-11041 | [1] | Plug | |
| 28 | SA9415-11051 | [1] | Plug | |
| 29 | SA9415-31021 | [2] | Plug | |
| 30 | VOE14880068 | [1] | Plug | |
| 31 | SA9451-02243 | [1] | Hose assembly | |
| 32 | SA9451-02246 | [2] | Hose assembly | |
| 33 | SA9451-02250 | [1] | Hose assembly | |
| 34 | SA9451-03265 | [1] | Hose assembly | |
| 35 | SA9451-02218 | [1] | Hose assembly | S/N -85051 |
| 36 | SA9451-02227 | [1] | Hose assembly | S/N -85051 |
| 37 | SA9452-04148 | [1] | Hose assembly | |
| 38 | SA9453-02208 | [1] | Hose assembly | S/N -85051 |
| 39 | SA9453-02210 | [1] | Hose assembly | |
| 40 | SA9453-02216 | [1] | Hose assembly | |
| 41 | SA9453-02226 | [1] | Hose assembly | |
| 42 | SA9453-02227 | [1] | Hose assembly | S/N -85051 |
| SA9453-02218 | [1] | Hose assembly | S/N 85052- | |
| 43 | SA9453-02228 | [1] | Hose assembly | S/N -85051 |
| SA9453-02214 | [1] | Hose assembly | S/N 85052- | |
| 44 | SA9453-02242 | [1] | Hose assembly | |
| 45 | SA9453-03213 | [1] | Hose assembly | |
| 46 | VOE983524 | [1] | O-ring | |
| 47 | VOE993320 | [8] | O-ring | S/N -85051 |
| VOE993320 | [4] | O-ring | S/N 85052- | |
| 48 | VOE983502 | [16] | O-ring | |
| 49 | VOE983505 | [1] | O-ring | |
| 50 | VOE993321 | [2] | O-ring | |
| 51 | VOE990557 | [2] | O-ring | |
| 52 | VOE946440 | [0002] | Flange screw | |
| 53 | VOE946441 | [0002] | Flange screw | |
| 54 | VOE983248 | [2] | Hexagon screw | |
| 55 | VOE983257 | [2] | Hexagon screw | |
| 56 | VOE955922 | [2] | Spring washer | |
| 57 | VOE993835 | [6] | Plain washer | |
| 58 | VOE983505 | [1] | O-ring | S/N -85501 |
| 58 | VOE993320 | [1] | O-ring | S/N 85502- |
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
